Detailing

Certified Mechanical & Structural Engineer Designs
3D Rendered Modeling of any Mechanical Plant & Steel Structures, Providing a Holistic View of the Intended Project
Effective Clash Detection Before Fabrication
Seamless Engineering Analysis on Structures
Provision of Complete Shop Fabrication Detailing
Component Numbering for Easy Tracking & Assembly
Generation of Exact Material & Plate Lists
Provision of .DXF Drawings & NC Files for Plate Profiling & Beam Lines
Accurate Bolt Listing
Fabrication Completion Tracking to Pinpoint Accuracy
3D Erection Drawings for Quick & Effective Erection
Provision of Wrap-around & Developing of Intricate Plate work
Generation of Weld Mapping and Weld Matrix Documentation for Accurate Traceability in the QC process
Complete Project QS Function

The Future of Detailing
